Welcome back to your Terraform journey.

In the previous tasks, you have learned about the basics of Terraform, its configuration file, and creating an EC2 instance using Terraform. Today, we will explore more about Terraform and create multiple resources.

Task:

Set the version of the terraform using terraform.tf file and start your task.

Create a VPC (Virtual Private Cloud) with CIDR block 10.0.0.0/16

  • Create a file called aws-vpc.tf

  • Set the cidr_block attribute to "10.0.0.0/16" to specify the IP address range for the VPC.

  resource "aws_vpc" "day66_vpc" {
    cidr_block = "10.0.0.0/16"

    tags = {
      Name = "day66_vpc"
    }
  }

Create a public subnet with CIDR block 10.0.1.0/24 in the above VPC.

  • Create a file called aws-public-subnet.tf

  • Set the vpc_id attribute to the ID of the VPC created in the previous step.

  • Set the cidr_block attribute to "10.0.1.0/24" to specify the IP address range for the subnet.

  resource "aws_subnet" "day66_public_subnet" {
    vpc_id     = aws_vpc.day66_vpc.id
    cidr_block = "10.0.1.0/24"

    tags = {
      Name = "day66_public_subnet"
    }
  }

Create a private subnet with CIDR block 10.0.2.0/24 in the above VPC.

  • Create a file called aws-private-subnet.tf

  • Set the vpc_id attribute to the ID of the VPC.

  • Set the cidr_block attribute to "10.0.2.0/24" for the subnet IP address range.

  resource "aws_subnet" "day66_private_subnet" {
    vpc_id     = aws_vpc.day66_vpc.id
    cidr_block = "10.0.2.0/24"

    tags = {
      Name = "day66_private_subnet"
    }
  }

Create an Internet Gateway (IGW) and attach it to the VPC.

  • Create a file called aws-internet-gateway.tf

  • Attach the Internet Gateway to the VPC by setting the vpc_id attribute.

  resource "aws_internet_gateway" "day66_igw" {
  vpc_id = aws_vpc.day66_vpc.id

  tags = {
    Name = "day66_igw"
  }
}

resource "aws_route_table" "day66_route-table" {
  vpc_id = aws_vpc.day66_vpc.id

  // If the route already exists, ignore changes to it
  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.day66_igw.id
  }

  lifecycle {
    ignore_changes = [
      route,
    ]
  }

  tags = {
    Name = "day66_routetable"
  }
}

Create a route table for the public subnet and associate it with the public subnet. This route table should have a route to the Internet Gateway.

  • Create file called aws-route-table.tf

  • Associate the route table with the public subnet by setting the vpc_id attribute.

  • Add a route to the Internet Gateway using the aws_route resource block.

  resource "aws_route_table" "day66_routetable" {
    vpc_id = aws_vpc.day66_vpc.id

    route {
      cidr_block = "0.0.0.0/0"
      gateway_id = aws_internet_gateway.day66_igw.id
    }

    tags = {
      Name = "day66_routetable"
    }
  }

  resource "aws_route_table_association" "public_subnet_association" {
    subnet_id      = aws_subnet.day66_public_subnet.id
    route_table_id = aws_route_table.day66_routetable.id
  }

  resource "aws_route_table_association" "private_subnet_association" {
    subnet_id      = aws_subnet.day66_private_subnet.id
    route_table_id = aws_route_table.day66_routetable.id
  }

Launch an EC2 instance in the public subnet with the following details:

  • Create a file called aws-instance.tf

  • Set the ami attribute to "ami-04b70fa74e45c3917" for the Amazon Machine Image (AMI).

  • Create a new key pair

  • Set the instance_type attribute to "t2.micro" for the instance type.

  • Specify a security group that allows SSH access from anywhere.

  • Use the user_data attribute to provide a shell script that installs Apache and hosts a simple website.

  resource "aws_security_group" "day66_sg" {
    name_prefix = "day66_sg"
    vpc_id      = aws_vpc.day66_vpc.id

    ingress {
      from_port   = 80
      to_port     = 80
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    ingress {
      from_port   = 443
      to_port     = 443
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    ingress {
      from_port   = 22
      to_port     = 22
      protocol    = "tcp"
      cidr_blocks = ["0.0.0.0/0"]
    }

    egress {
      from_port        = 0
      to_port          = 0
      protocol         = "-1"
      cidr_blocks      = ["0.0.0.0/0"]
      ipv6_cidr_blocks = ["::/0"]
    }

  }

  resource "aws_instance" "day66_ec2instance" {
    ami           = "ami-04b70fa74e45c3917"
    instance_type = "t2.micro"
    key_name      = "day66-key"
    subnet_id     = aws_subnet.day66_public_subnet.id
    security_groups = [
      aws_security_group.day66_sg.id
    ]

    user_data = <<-EOF
                  #!/bin/bash
                  sudo apt update
                  sudo apt install -y apache2
                  sudo systemctl start apache2
                  sudo systemctl enable apache2
                  echo "<html><body><h1>Welcome to DevOpsParthu community!!</h1></body></html>" > /var/www/html/index.html
                  sudo systemctl restart apache2
                  EOF
    tags = {
      Name = "day66_ec2instance"
    }
  }

Create an Elastic IP and associate it with the EC2 instance.

  • Create a file called aws-elastic-ip.tf

  • Associate the Elastic IP with the EC2 instance by setting the instance attribute to the ID of the instance.

  resource "aws_eip" "day66_eip" {
    instance = aws_instance.day66_ec2instance.id
  }

Create a keypair

  • Create a file called keypair.tf
resource "aws_key_pair" "day66-key" {
  key_name   = "day66-key"
  public_key = file("/home/ubuntu/.ssh/day66-key.pub")
}

Open the website URL in a browser to verify that the website is hosted successfully.

terraform init

terraform apply

By following these steps, you will build your AWS infrastructure using Terraform. Remember to clean up your resources after completing the project to avoid unnecessary costs.

Congratulations on completing Day 66 of the #90DaysOfDevOps Challenge. Stay tuned for Day 67, where we'll explore AWS S3 Bucket Creation and Management with Terraform.
