On your journey of making a CI/CD pipeline on AWS with these tools, you completed AWS CodeCommit.

Next few days you'll learn these tools/services:

CodeBuild

CodeDeploy

CodePipeline

S3

What is CodeBuild?

AWS CodeBuild is a fully managed build service in the cloud. CodeBuild compiles your source code, runs unit tests, and produces artefacts that are ready to deploy. CodeBuild eliminates the need to provision, manage, and scale your build servers.

Task-01 :

Read about the Buildspec file for Codebuild.

A buildspec.yml is the YML/YAML file formated used in AWS CodeBuild to define your project's build command and setting. This file specifies how code build should build and test your code. Here are some examples and details of buildspec.yml the file.

Examplebuildspec.ymlfile:-

version: 0.2

env:
  variables:
    NODE_ENV: production

phases:
  install:
    runtime-versions:
      nodejs: 14
    commands:
      - echo Installing dependencies...
      - npm install
  pre_build:
    commands:
      - echo Running pre-build phase...
      - npm run lint
  build:
    commands:
      - echo Build started on `date`
      - npm run build
  post_build:
    commands:
      - echo Build completed on `date`
      - npm test

artifacts:
  files:
    - '**/*'
  discard-paths: yes

cache:
  paths:
    - 'node_modules/**/*'

Detailed Explanation of YAML/YML file:-

1.version: Specify the version of the CodeBuild, currently using 0.2

2.env : Specify the environment variable, parameters-store variable secert-manager variable and more.

variable : Define the environment variable that can be used throughout the build process.
parameter-store : Allows you to pull value from the AWS system manager parameter store.
secrets-manager : Allows you to pull secrets from AWS secerts-manager.

3.phase : Defining the sequence of commands to run in different stages of the build process.

install : This phase is used to write a command to install all dependencies required for the build process. which means a command to run the build start (eg:- installing dependencies).
pre-build : This phase is used for any commands to run before the actual build process. which means the command to run before the build process (eg:- preparing the environment).
build : This phase mainly builds commands like compiling code, running scripts or creating packages. which means commands to compile, build or package the source code.
post-build : This phase includes testing and deployment commands. which means a command to run after the build (eg:- testing, deployment).

4.artifacts : Specify the file and directory to be uploaded to the output of the artefact bucket.

5.cache : Specify the file and directory to be cached to speed up the subsequent builds.

The buildspec.yml file is a powerful way to define your build process in AWS CodeBuild. By understanding its structure and capabilities, you can customize and optimize your builds to meet your specific needs.

Create a simple index.html file in the CodeCommit repository.

Open your AWS Management Console and navigate to the CodeCommit service. On the right side, click on Create Repository and enter your repository name as DAY-51-NGINX. Write a description and click on Create.

After that, you will automatically enter your repository. Scroll down and you will see the Create file. Click on it.

On Day-50, copy the index.html file you created and paste it into the CodeCommit file in the Day-51-NGINX repository. Scroll down to the "Commit changes to main" section. You must enter the file name, author name, email address, and commit message there. Finally, click on "Commit changes."

After that, on the right side, select clone URL, click on Clone HTTPS, copy that URL, and clone it to your local machine but it will ask for credentials you can past Day-50's credentials.

You have to build the index.html using the NGINX server.

This will be covered in TASK-2.

Task-02 :

Add buildspec.yaml file to CodeCommit Repository and complete the build process.

On your local machine, create a file called buildspec.yml, then commit and push it to your CodeCommit repository.

vim buildspec.yml

version: 0.2

phase:
  install:
    commands:
      - echo installing NGINX
      - sudo apt-get update
      - sudo apt-get upgrade -y
      - sudo apt-get install nginx -y
  build:
    commands:
      - echo build started on 'date'
      - cp index.html /var/www/html/
  post_build:
    commands:
      - echo configuring NGINX
artifacts:
  files:
     - '**/*'

git add <filename>
git commit -m "<commit messgae>"
git branch
git push origin <branch name>

Now go to the CodeCommit Console and refresh the page. You will see both the index.html and buildspec.yml files.

Now you have to build that file in the CodeBuild service. To do that, navigate to the CodeBuild console and click on Create project.

In the project configuration, you have to write the name of the project.

In the Source, you have to select AWS CodeCommit, and in the Repository, select the Day-51-NGINX repository and the Branch of the repository.

In the Environment section, keep the Provisioning model, Environment image, and Compute as default, and select Ubuntu in the Operating system.

In the Buildspec section, choose Use a buildspec file and unselect cloudwatch in the logs. Keep the rest as default and then click on Create build project.

After that, click on Start Build and check the phase details. All should come in success status.

Now we have to store the artifacts in the S3 bucket. For that, navigate to the S3 bucket console and create a bucket called day-51-bucket.

Now come back to the CodeBuild console, click on Build projects, select your build project, and at the top, click on Edit. Scroll down to Artifacts, select Amazon S3, and in Bucket name, select the bucket you created. In the Name field, write the bucket name folder and click on Update project. Then click on Start build and in phase details, all should come in success status.
